Features
- Extra Wide Display
- Edge to Edge Design
- High Resolution Visuals
- Versatile Content Presentation
- Customizable Content
- Durable Construction
- Remote Management
- Space Saving Installation
Technical Specifications
| Panel Type | A Si TFT LCD, CELL, FOB |
| Resolution | 1366 (RGB) x 768 (RGB), WXGA 49PPI |
| Pixel Format | RGB Horizontal Stripe |
| View Direction | Symmetry |
| Viewing Angle | 89 to 89 to 89 to 89 (Typ.) (CR ≥10) |
| Frame Rate | 60 Hz |
| D-IC Detail | COF Builtin 1 source + 3 gate chips |
| Interface Type | LVDS (8 bit), 30 pins Connector |
| Power Supply | 12 V |
| Treatment | Antiglare (Haze 2%), Hard coating |
| Contrast Ratio | 3000:1 |
| Response Time | 6.5 s |
| Operating Mode | HVA, Normally Black, Transmissive |
| Transmittance | 7.16% (Typ.) (with Polarizer) |
| Light Source | No Backlight |
| Touch Panel | Without |
| Diagonal Size | 32 in (812.8 mm) |
| Storage Temperature | -68 °F to 140 °F (-20 °C to 60 °C) |
| Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Active Area | 27.46 in x 15.44 in (697.685 mm x 392.256 mm) |
| Outline Dim. | 28.15 in x 16.16 in x 0.05 in (715.03 mm x 410.57 mm × 1.43 mm) |
