Features
- Display Size
- LCD Type
- Resolution
- Wide Viewing Angle
- High Brightness
- Fast Response Time
- RS232 Compatibility
- Quality Build
- Cost Efficient
Technical Specifications
| Resolution | 320 Pixel x 240 Pixel |
| Display mode | Normally White, Transmissive 54 PIN |
| Driver IC | ILI 9322 or equivalent |
| Interface | RGB 24 bits Interface |
| Touch Panel | Customized with capacitive and resistive Touch Panel |
| Backlight | 8 white LEDs Backlight |
| Size | 4.0 In (101.6 mm) TFT LCD Module |
| Outline Dimension | 3.78 in x 2.99 in x 0.12 in (96.05 mm x 76.05 mm x 3.3 mm) |
| Active Area | 3.23 in x 2.42 in (82.08 mm x 61.56 mm) |
