Overview
Hospitality Enviro Tech I / O ports fanless PC is a new, industrial box PC equipped with an Intel® Core 3rd Generation i3 i5 i7 processor. Meeting the demands of harsh environments, the fanless design makes the IPC-302A extra reliable for applications in the machine building industry. In addition, the dual GbE LAN, 6 x serial ports, 6 x USB ports, make device connection and integration easy.
Features
- Fan-less Cooling System
- Compact and Wireless Design.
- Wide Working Temperature 14 °F to 140 °F
- Onboard CPU and Memory
Technical Specifications
| CPU | Onboard intel® core 3th gen CPU, i3 / i5 / i7 |
| Cooling System | Fan-less |
| Memory | Onboard 2 GB DDR3, max 16 GB dual channel |
| Storage | SSD + HDD |
| I/O Ports | USB: 6 x USB 2.0 (optional 2 x USB 2.0, 4 x USB 3.0) |
| COM: 6 x RS 232 | |
| Dual Display: 1 x VGA + 1 x HDMI | |
| Audio: 1 x mic-in, 1 x line-out | |
| LAN: 2 x 10 Mbps / 100 Mbps / 1000 Mbps ethernet | |
| Input Voltage | 12 V DC (Aviation Connector), optional 9 V to 36 V DC |
| OS Support | Windows XP / 7 / 8 / 10 / linux |
| Operating Temperature | 14 oF to 140 oF (-10 oC to 60 oC) |
| Storage Temperature | -4 oF to 167 oF (-20 oC to 75 oC) |
| Dimensions | 8.27 in x 7.87 in x 2.76 in (210 mm x 200 mm x 70mm) |
| Weight | 55.26 lb (2.5 Kg) |
