Features
- PCAP 10-point multi-touch technology, accuracy and fast
- High brightness options from 1000 cd/m2 to 3000cd/m2
- Sunlight readable & automatic brightness adjustment
- IP 65 waterproof (front face), anti-glare, dust-proof and vandal-proof
- Pure flat, zero bezel design embedded lcd monitor
- Multiple interfaces like VGA, DVI, HMDI, DP, USB/RS232
- Multiple mounting options including L-brackets and VESA mount
- CCC, UL, FCC, CE, CB, RoHs
- Best choice for outdoor applications, also suitable for Gaming/Casino, Medical, ATM
Technical Specifications
| Series | OT |
| Display Type | 5:4 Ratio 17 in TFT-LCD |
| Suggested Resolution | 1280 x 1024 at 60Hz |
| Support Colours | 16.7 M |
| Brightness (Typ.) | Pure LCD Panel 250 cd / m2 |
| With Touch Monitor 212 cd / m2 | |
| Response Time (Typ.) | 5 ms |
| Viewing angle (Typ.atcr>10) | Horizontal (left / right) 85° / 85° Vertical (up / down) 80° / 80° |
| Contrast Ratio (Typ.) | 1000:1 |
| Video Input | VGA / DVI |
| LED Back Light Life (Typ.) | ≥30,000 Hours |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤20W |
| Mount Interface | 1.VESA 2.95 in (75 mm) and 3.93 in (100 mm) 2.Mount bracket, horizontal or vertical mount |
| Environment | Operating Temp. 32 °F to 122 °F (0 °C to 50 °C) Operating RH 20% to 80%
Storage Temp. -4 °F to 140 °F (-20 °C to 60 °C) Storage RH 10% to 90% |
| Active Area | 13.3 in x 10.64 in (337.9 mm x 270.3 mm) |
| Monitor dimensions | 14.92 in x 12.33 in x 1.87 in (378.9 mm x 313.3 mm x 47.3 mm) |
