Key Features
- Ultra-thin shell, more easily to hold
- Suitable for multiple impact devices and 6 types of hardness scales are available for various applications
- Large and clear digital display
Technical Specifications
| Hardness Scales | HL、 HRC、HRB、HV、HB、HS |
| Repeatability Accuracy | HLD：±6 HRC：±1 HB：±4 |
| Accuracy | +/- 0.5% |
| Standard Impact Device | impact device of Type D |
| Upper / Lower Limits Setting | （170～960）HLD |
| Optional Impact Device | D/ C /DC / D+15 / DL/ G |
| PC Interface | USB 2.0 |
| Screen Display | 128X64 dot matrix LCD, backlight and adjustable contrast |
| Measuring Direction | 360° |
| Data Memory | 100 group of readings |
| Max. Hardness of The Measured Work Piece | 940HV（for D,DC,DL,D+15,C impact device） |
| Radius of Curvature of The Measured Work | Rmin=1.9 in (50mm） |
| Recognition Function | Recognize the type of the impact device by itself |
| Power Supply | 3×1.5V AAA |
| Dimensions | 4.5 x 2.6 x 1.0 in(155mm x 68mm x 27 mm) |
| weight | 0.55lbs.(250g) |
