Features
- Wide velocity range up to 200 mm/s makes it suitable for pumps and industrial rotating machinery.
- High sampling granularity: from 1 Hz to 25.6 kHz with 4096 sampling points — good for capturing transient vibration events.
- Accurate & robust sensor: ±1% accuracy and stainless steel housing; built to endure typical industrial conditions.
- Two-wire 4-20 mA output means simpler wiring into existing PLC or SCADA loops.
- Decent temperature tolerance: operates from ‒20 °C to +100 °C — works in cold or hot environments but not extreme.
- Relatively heavy: ~0.5 kg gross — mounting needs proper support.
- Custom branding available: good if you want to re-sell under your brand, but check actual minimum order costs.
Technical Specifications
| Specification | Details |
| Measuring Parameter | Vibration velocity |
| Measuring Range | 0 to 200 mm/s |
| Output Type | 4-20 mA two-wire system |
| Temperature Measurement | ‒20 °C to +100 °C |
| Measurement Accuracy | ±1 % |
| Sampling Rate | 1 Hz to 25.6 kHz |
| Sampling Points | 4096 |
| Shell / Housing Material | Stainless steel |
| Load Resistance | < 500 Ω |
| Supply Voltage | 5 to 24 V DC |
| Operating / Mounting Type | Arbitrarily mounted sensor |
| Package Size | 4.33 × 4.33 × 1.57 in |
| Gross Weight | 1.10 lb |
| Customization Options | Logo, packaging, graphics |
