Overview
Hospitality Enviro Tech Wireless Soil pH & Moisture Tester with RS485 Weather Station integrates soil condition testing with advanced meteorological monitoring. It measures soil pH and moisture while also tracking particulate matter, wind, rainfall, noise, illumination, and UV radiation. Sourced from a Chinese manufacturer specializing in environmental monitoring systems, this device supports RS485 Modbus or optional 4G transmission. Its rugged metal housing, solar or AC power options, and IP53 protection rating make it suitable for agricultural, meteorological, and industrial environmental applications.
Features
- Soil pH and moisture measurement with RS485 Modbus data output
- Supports PM2.5, PM10, and TSP particulate monitoring
- Tracks temperature, humidity, wind speed, wind direction, and noise
- Rainfall, illumination, and UV radiation detection
- Data transmission via RS485, RS232, USB, SD card, or 4G LTE
- Cold rolled steel plate construction with IP53 protection
- Flexible power supply (AC110–230 V or optional solar)
- Outdoor pole-mounted installation for durable use
Technical Specifications
| Specification | Value |
| Detection Method | Diffusion or suction |
| Data Transmission | RS485 Modbus, RS232, USB, SD card, or 4G LTE |
| Preheat Time | 90 seconds |
| Temperature Range | -22 °F to 122 °F (-30 °C to 50 °C) |
| Humidity Range | 0% to 95% RH (no condensation) |
| Wind Speed | 0 to 134 mph (0 to 60 m/s), resolution 0.22 mph (0.1 m/s), ±2.2 mph (±1 m/s) |
| Wind Direction | 0° to 360°, resolution 1° |
| Atmospheric Pressure | 8.7 PSI to 15.9 PSI (600 hPa to 1100 hPa), resolution 0.01 PSI (1 hPa) |
| Noise | 30 dB(A) to 130 dB(A), accuracy ±3 dB |
| Rainfall | 0 to 0.16 in/min (0 to 4 mm/min), resolution 0.004 in (0.1 mm), ±0.016 in (≤0.39 in) or ±4% (>0.39 in) |
| Illumination | 0 to 200,000 Lux, ±7% at 77 °F (25 °C) |
| UV Radiation | 0 to 400 mW/m², resolution 1 mW/m², ±5% |
| Particulate Monitoring | PM2.5, PM10, TSP (0 to 1000 µg/m³, resolution 1 µg) |
| Power Supply | AC110–230 V or optional solar, 80 W max |
| Material | Cold rolled steel plate |
| Protection Class | IP53 |
| Dimensions | 24.4 in x 17.3 in x 6.3 in (620 mm x 440 mm x 160 mm) |
| Weight | 55.1 lb (25 kg) |
| Installation | Outdoor Pole Mounted |
