Features
- Wireless IoT connectivity with LTE support
- Advanced industrial design for stable operations
- Multiple communication interfaces for versatile applications
- Robust security protocols for data protection
- Easy-to-configure web-based interface
Technical Specifications
| Processor | 880 MHz CPU, Cortex A7 architecture |
| Operating System | Embedded Linux OS |
| RAM | 128 MB DDR2 |
| Storage | 16 MB NorFlash |
| Network Interfaces | 1 × 10/100 Mbps LAN, 1 × 10/100 Mbps WAN |
| WiFi | 2.4 GHz, IEEE 802.11 b/g/n |
| SIM Support | 1 standard SIM card slot |
| I/O Ports | 1 × RS232, 1 × RS485, 2 × DI, 2 × DO |
| Power Supply | 9 to 48 VDC |
| Power Consumption | < 5 Watts |
| Operating Temperature | -13°F to 158°F (-25°C to 70°C) |
| Storage Temperature | -40°F to 185°F (-40°C to 85°C) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Antenna | 2 × SMA (1 cellular, 1 WiFi) |
| Certifications | CE, RoHS |
| Dimensions | 3.94 × 2.36 × 1.18 in (100 × 60 × 30 mm) |
| Weight | 0.44 lb (200 g) |
