Technical Specifications
| Parameter | Specification |
| Measuring Range | 50 g / 100 g / 200 g |
| Sensitivity (25 °C) | 100 mV/g / 50 mV/g / 25 mV/g |
| Frequency Response (±3 dB) | 8,000 Hz |
| Resonant Frequency | 20,000 Hz |
| Transverse Sensitivity | ≤ 2% |
| Excitation Voltage | 18–28 VDC |
| Constant Current Excitation | 2–10 mA |
| Bias Voltage | 10–12 VDC |
| Output Impedance | < 100 Ω |
| Insulation Resistance to Ground | 100 MΩ |
| Operating Temperature | −50 to +150 °C |
| Shock Limit (Peak) | 5,000 g |
| Overall Dimensions | 45 mm × 23.5 mm |
| Weight | 110 g ± 5 g |
| Housing Material | 316 Stainless Steel |
| Connector Type | 5015 four-pin |
| Mounting Type | 1/4-28 UNF thread |
| Sensing Technology | MEMS |
| Optional Cable Length | 3 m or 5 m |
