Overview
These wide range water quality testers are engineered with advanced electromagnetic technology, offering precise measurement for industrial and irrigation needs. Built with stainless steel 304 housing, they ensure durability and resistance in challenging environments. The meters deliver high accuracy across flow rates, maintaining reliability even under submerged conditions thanks to their IP68 protection. Equipped with multiple smart communication options such as NB-IoT, LoRa, LoRaWAN, M-Bus, and RS485, they integrate seamlessly with monitoring systems. The devices support long-term data logging, provide tamper detection, and allow flexible installation in both horizontal and vertical orientations, ensuring robust performance for diverse applications.
Features
- Electromagnetic smart water metering technology
- Wide measurement range from 0.4 to 200 m³/h
- IP68-rated enclosure for submersible conditions
- Stainless steel 304 body for corrosion resistance
- Accuracy class of ±0.5% (±0.2% optional)
- Multiple output options including IoT connectivity
- Long-lasting lithium battery or external power supply
- LCD digital display with backlight for readability
- Data logging with storage up to 24 months
- Tamper and reverse flow detection for security
Technical Specifications
| Type | Electromagnetic Smart Water Meter |
| Kind | Smart Water Meter |
| Protection Class | IP68 |
| Flow Rate | 160 m³/h |
| Measurement Range | 0.4 m³/h – 200 m³/h |
| Metrological Ratio | R250 / R400 |
| Size Availability | DN40 / DN50 / DN65 / DN80 / DN100 / DN125 / DN150 / DN200 / DN250 / DN300 |
| Material of Body | Stainless Steel 304 |
| Application | Industrial / Irrigation |
| Customized Support | OEM, ODM |
| Output Options | NB-IoT / LoRa / LoRaWAN / M-Bus / RS485 |
| Potable Water Certificate | WRAS (in processing) |
| Measuring Certificate | MID 2014/32/EU (in processing) |
| Accuracy Class | ±0.5% for standard flow, ±0.2% optional |
| Operating Pressure Range | ≤ 1.6 MPa |
| Ambient Temperature | -25°C to +55°C |
| Medium Temperature | 0°C to +50°C (potable water) / 0°C to +70°C (other liquids) |
| Power Supply Options | Lithium battery (up to 6 years) / External power supply |
| Communication Protocols | Modbus, DLMS/COSEM, Optional integration with cloud-based platforms |
| Installation Orientation | Horizontal or Vertical |
| Display Type | LCD digital display with backlight |
| Data Logging Capability | Internal memory supports up to 24 months of historical consumption data |
| Tamper Detection | Magnetic and reverse flow detection |
| Ingress Protection Features | Fully sealed design suitable for submerged conditions |
