Technical Specifications
| Protocol | IEEE802.11ah |
| Frequency Range | 730 MHz to 790 MHz, Center Frequency 775 MHz |
| Bandwidth Options | 1 MHz, 2 MHz, 4 MHz, 8 MHz |
| Max Transmission Power | 20 dBm |
| Modulation and Coding Scheme (MCS) | 0 to 7, 10 (only for 1 MHz) |
| Data Rates | 150 Kbps to 32.5 Mbps |
| Transmission Distance | 0.75 mi (1.2 km), >4 Mbps @ 8 MHz bandwidth |
| Average Power Consumption | Approx. 110 mA |
| Heartbeat Connection Power Consumption | 500 µA |
| Operating Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Dimensions | 3.9 in x 3.1 in x 0.6 in (10 cm x 8 cm x 1.5 cm) |
| Weight | 0.07 lb (0.031 kg) |
