Key Features
- 63A:AC output2Vpeak
- 0-40degree operation condition
- 10K or more Load impedance
- 001~1.999mm P-P Displacement
Technical Specifications
| Measuring range | Acceleration:0.1~199.9m/s |
| Velocity:0.1~1999.9mm/s rms | |
| Displacement:0.001~1.999mm P-P | |
| Measuring Accuracy | ±5% |
| Vibration pickup | Piezoelectric ceramic accelerometer (Shear-type) |
| Measurement frequency range of acceleration | 10Hz~1KHz(LO);
1KHz~15KHz(HI) |
| Measurement frequency range of velocity | 10Hz~1KHz(LO) |
| Measurement frequency range of displacement | 10Hz~1KHz(LO) |
| LCD display | 3.5digitala display |
| Single output | 63A:AC output2Vpeak (display full scale) |
| Load impedance 10Kor more | |
| Earphones can be connected; | |
| 63B:NO | |
| Max hold function | 63B: √ |
| Temperature selection | 63B:√ |
| Operation condition display | 63B:√ |
| Operation condition | 0-40degree |
| Power supply | 9V |
| Unit size | 3.15×1.5×5.9 inch (80x38x150mm) |
