Overview:
The Hospitality Enviro Tech ultrasonic thickness gauge adopts the interface echo and bottom echo difference (IE) thickness measurement principle and pulse reflection (PE) ultrasonic measurement principle. It can measure the thickness of the product through the coating. At the same time, it is also equipped with a test function to check whether the precious metals are adulterated and identify the purity. It is primarily used for identifying gold bars, silver bars, gold coins, silver coins, and other precious metals. This instrument can accurately measure all kinds of plates and processed parts. It is widely used in the petroleum, chemical, metallurgy, shipbuilding, aviation, aerospace, and other industries.
Features:
- Three measurement modes, P-E, I-E, and TEST, are adopted to accurately measure the thickness. I-E mode enables the gauge to measure thickness through coating.
- High precision timing chip and V-path calibration model are adopted, with a wide measurement range and high measurement accuracy.
- The measurement information can be completely stored, including the thickness measurement value, the measured sound velocity, and time information.
- The display resolution can be 0.1mm/0.01mm.
- The contrast of the liquid crystal display is adjustable, and it has an LED backlight display, which can be used in various light environments.
Technical Specifications:
| Measurement mode | P-E /I-E /TEST |
| Measuring range | 0.75 mm to 300 mm（optional） |
| Accuracy | H<10mm ±0.05mm
H≥10mm ±(0.05mm+H/100)mm |
| Measurement resolution | 0.01mm or 0.1mm（optional） |
| Display screen | 2.0 in FSTN,128*64 dot matrix, LED backlight |
| Measurable material | Steel, iron, glass, plastic, aluminium, etc. |
| Velocity Range | 1000 to 9999m/s |
| Continuous Working time | 50 hours （without backlight） |
| Data Storage | 500 groups of measurement results, including measurement time and sound velocity information |
| Unit | mm or inch |
| Operating temperature | 0℃ to 50℃ |
| Auto Power off | Automatic shutdown without action for 2 minutes (settable), with a switch button |
| Power supply | Two 1.5V AA batteries |
| Size | 150 mm x 71 mm x 33 mm |
| Weight | 160 g |
