Technical Specifications
| Flow Range | 0.1 m/s to 5.0 m/s |
| Accuracy | ± 2.0% F.S. |
| Repeatability | 0.8% F.S. |
| Measurement Tube Diameter | Φ 9.53 to φ 3.5 in (9.53 mm to 90 mm) |
| Storage Function | With daily, monthly and yearly flow accumulation function |
| Analog Output | 4 mA to 20 mA, maximum load 600 Ω |
| Alarm Output | OCT upper and lower limit alarm function (option) |
| Communication Interface | RS485, support MODBUS communication protocol |
| Power Supply | 24 V DC |
| Cable Length | 2.0 m |
| Keypad | Four light touch keys |
| Display | OLED 128 x 64 dot matrix display |
| Units | Support metric and imperial unit selection, Cubic Meters (m³), Liter (L), USA Gallons (GAL), Available in /hour (per hour), /min (per minute), factory default unit is m³/h |
| Accumulator | 6 position flow accumulators |
| Suitable For Tubes | Stainless steel, carbon steel, copper tube, plastic tube |
| Housing Material | Aluminium alloy |
| Ambient Temperature | 32 ℉ to 122 ℉ (0 ℃ to 50 ℃) |
| Medium Temperature | 32 ℉ to 122 ℉ (0 ℃ to 50 ℃) |
| Ambient Humidity | Relative humidity 0% to 95%, no condensation |
| Protection Class | IP54 |
