Features
- Ultrasonic pulse method for crack depth detection
- Measures crack depth up to 650 mm
- Accuracy within ≤10%
- Portable and compact design (208 × 168 × 85 mm)
- IP55 protection (dust and splash resistant)
- Powered by 9V DC, easy to operate
- Non-destructive testing, no structural damage
- 1-year warranty with factory support
Technical Specifications
| Specification | Details |
| Type | NDT Ultrasonic Tester |
| Color | Yellow |
| Keyword | NDT Ultrasonic Tester |
| Standard | CECS 21:2000 |
| Power | 6 pcs No. 5 battery (AA type) |
| Crack Depth Accuracy | ≤ 10% |
| Crack Depth Test Range | ≤ 650 mm (25.59 in) |
| Voltage | 9 VDC |
| Protection Class | IP55 |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Weight | 2.2 lb (1 kg) |
| Main Host Dimension | 8.19 in x 6.61 in x 3.35 in (208 mm x 168 mm x 85 mm) |
