Features
- Tri-axis capability: Measures vibration across three axes without needing reorientation—faster, more comprehensive checks.
- Decent field accuracy: ±5% linearity isn’t lab-grade but solid for maintenance diagnostics.
- Broad usability: 10–1000 Hz covers most rotating machinery cases for industrial monitoring.
- User-friendly: Simple 3½-digit LCD — no gimmicks, just clear readings.
- Long battery life: 25-hour runtime on a standard 9 V — great out-of-the-box, but battery type is uncommon; always carry a spare.
- Portable but chunky: Handheld dimensions make it mobile, but at 350 g, it isn’t feather-light.
- OEM-ready: Custom branding and options available—expect some minimums and markups.
- Warranty covers basics: A year is standard; no IP rating mentioned—keep it dry and clean
Technical Specifications
| Specification | Details |
| Measurement Range | 0 to 1999 µm (peak-to-peak) / 0 to 199.9 mm/s (RMS) / 0 to 199.9 m/s² (overall peak) |
| Linearity & Accuracy | ±5% |
| Frequency Response | 10–1000 Hz |
| Display | 3½-digit LCD |
| Power Supply | 9 V battery (6F22 type) |
| Battery Life | ~25 hours continuous use |
| Operating Temperature | 0 to 40 °C |
| Dimensions (HxWxD) | 185 × 68 × 30 mm (7.28 × 2.68 × 1.18 in) |
| Weight (incl. battery) | 350 g (~12.3 oz) |
| Customization Options | OEM, ODM, OBM support |
