| Specification |
Details |
| Display & Interface |
3.5-inch IPS TFT capacitive touchscreen (640×480 pixels) |
| Measurement Channel |
CH1: ICP accelerometer or ±5 V AC voltage input |
| Frequency Range / Sampling |
2 Hz – 10 kHz (selectable spans); sampling up to 25.6 kHz |
| Data Acquisition |
16-bit A/D (some sources list upgraded 24-bit) |
| Analysis Capabilities |
FFT spectrum, waveform, trend, waterfall, envelope, alarm threshold alerts |
| Infrared Temperature Measurement |
–30 °C to 420 °C; ±2 % or ±1.5 °C accuracy; adjustable emissivity; 25:1 ratio |
| Connectivity |
Wi-Fi and USB 2.0 for data sync and PC software integration (e.g., MOS3000) |
| Camera & Lighting |
5 MP autofocus camera with integrated flashlight |
| RFID & GPS (Optional) |
UHF 900 MHz RFID (approx. 20–30 cm range); GPS optional |
| Memory |
Internal: 1 GB; optional micro-SD up to 32 GB |
| Battery & Power |
Rechargeable Li-ion battery: Standard: 5000 mAh |
| Charging Time |
Standard: ~4.5 h; Explosion-proof: ~2.5 h |
| Build & Protection |
IP65, dustproof, waterproof, 2 m drop tested; backlit keypad (2 million key presses) |
| Weight |
~465 g (normal) / ~455 g (EX version) |
| Dimensions (L×W×D) |
195 × 80 × 37 mm; grip area: 68 × 31 mm |
| Operating Conditions |
–10 °C to 50 °C (some list –20 °C to 55 °C); humidity < 95% non-condensing |
| Certification & Optional Versions |
CE marked; National metrology verified; Explosion-proof Exib IICT4 Gb available |
