Features
- Supports 3-phase 380V to 440V input for solar water pumps.
- Rated power options: 4kW and 5.5kW.
- Variable Frequency Drive (VFD) with MPPT and V/F control modes.
- Overload capacity: 150% for 60s, 180% for 3s.
- Compact and durable design suitable for outdoor use.
- High efficiency and energy-saving operation for solar pump systems.
- Easy installation and user-friendly interface.
- Provides stable and reliable pump control for agricultural, residential, and industrial applications.
Technical Specifications
| Specification | Details |
| Control Mode | MPPT to V/F |
| Nominal Voltage | 380VAC to 250VDC-800VDC |
| Power Phase Number | 3 Phase |
| Rated Power | 4kW to 5.5kW |
| Type | AC to Solar DC |
| Application | Motor power ≤ 5.5kW |
| Ingress Protection | IP20 |
| Overload Capacity | 150% for 60s to 180% for 3s |
| Color | Black |
| Temperature | -4 °F to 131 °F (-20 °C to 55 °C) |
| Weight | 2.43 lb (1.1 kg) [Approx. for this size inverter] |
| Size | 7.40 in * 3.78 in * 6.73 in (188mm * 96mm * 171mm) |
