Parameter |
HETITC-108-A |
HETITC-108-B |
| Detector Data |
Type |
Uncooled FPA |
| |
IR Resolution |
384 × 288 |
640 × 480 |
| |
Pixel Pitch |
17 µm |
| |
Spectral Range |
7.5–14 µm |
| |
NETD/Sensitivity |
25 mK |
| Lens Data |
FOV |
24° × 18° |
| |
Minimum Imaging Distance |
0.3 m |
| |
IFOV |
1.13 mrad |
0.68 mrad |
| |
Focus |
Manual / Motor / Continuous Autofocus / Laser-Assisted Focusing |
| |
Lens Recognition |
Automatic |
| |
Lens (Optional) |
48° × 36°, 12° × 9° |
| |
Lens Rotation |
180° rotation |
| Image Performance |
Display |
HD 5″ Touch AMOLED, 1280×720 |
| |
Viewfinder |
0.5″ Color OLED, Manual Zoom, 1920×1080 |
| |
Visual Camera |
13 MP CMOS, Autofocus, LED Fill Light |
| |
Frequency |
50 Hz / 60 Hz |
| |
Amplification |
1×–35× Continuous |
| |
Palette |
12 Palettes (Iron Red, Rainbow, Black Hot, White Hot, etc.) |
| |
Brightness |
Auto / Manual |
| Measurement |
Temperature Range |
-20°C to +600°C (extendable to 1700°C) |
| |
Measurement Accuracy |
5°C–150°C: ±1°C or ±1% of reading; other ranges: ±2°C or ±2% of reading (whichever is larger) |
| |
Measurement Mode |
Real-time: 20 movable spots, 10 movable rectangular areas, and 10 circular areas (max/min/avg temp measurement). Includes line temp, isothermal analysis, temp difference measurement, and temp alarm (sound/color). |
| |
Measurement Correction |
Auto / Manual |
| |
Emissivity Correction |
Adjustable from 0.01 to 1.0 or selected from material list |
| |
Background Temperature Correction |
Auto (based on input background temperature) |
| |
Atmospheric Transmissivity Correction |
Auto (based on input distance, relative humidity, and ambient temperature) |
| |
Setting Functions |
Date/time, temperature unit (°C/°F/K), language |
| Alarm |
Sound and Light Alarm |
Yes |
| Image Storage |
Memory Card |
64 GB |
| |
Single Frame Infrared Image Format |
JPEG with 14-bit measured data |
| |
Single Frame Visible Image Format |
JPEG or stored with single frame image |
| |
Text Annotation |
Supports 30 editable preset text annotations |
| |
Voice Annotation |
60-second voice recording per image (built-in microphone) |
| Laser Indicator |
Grade / Type |
Class 2, 1 mW, 650 nm (Red) |
| |
Laser Ranging |
Measuring distance: 0.2 m – 50 m |
| Interfaces |
Power Interface |
Yes |
| |
SD Card Slot |
Yes |
| |
Video Output |
HDMI |
| |
Audio Output |
Yes |
| |
USB Interface |
USB Type-C (data transmission, radiometric video streaming) |
| |
Wi-Fi |
Yes |
| |
Bluetooth |
Yes |
| |
GPS |
Yes |
| |
Compass |
Yes |
| |
Tripod |
1/4″, _20 |
| Power System |
Battery Type |
Lithium battery (rechargeable) |
| |
Battery Operating Time |
4 hours continuous (at room temperature) |
| |
External Power |
DC: 5V |
| |
Charging System |
Two-seater charger or in-camera charging |
| |
Power Saving |
Yes |
| Environmental Parameters |
Operating Temperature Range |
-20°C to +50°C |
| |
Storage Temperature Range |
-40°C to +70°C |
| |
Humidity |
≤95% (non-condensing) |
| |
Vibration |
2G (IEC60068-2-6) |
| |
Shock |
25G (IEC60068-2-29) |
| |
Enclosure Rating |
IP54 (IEC60529) |
| Physical Data |
Size |
183 mm × 160 mm × 88 mm |
| |
Weight |
≤1.4 kg (including battery and standard lens) |
| Packing |
Standard Accessories |
Thermal imaging camera, 2 lithium batteries, battery charger, adapter, USB cable, SD card, HDMI cable, SD card reader, USB flash drive, warranty card, calibration book, carrying case, user manual |
| Quality Assurance |
Certification |
CE |
