Key Features
- The socket design for the xenon lamp and tungsten lamp, allows for for no optical debugging after changing light
- Large sample chamber can accommodate 5-100 mm various specifications of cuvette
- Can be directly connected to the printer to print patterns and experimental data
- Optional disk with automatic 8 joint cuvette holder
- Adopts 1200 bar/mm high-performance grating. New light control system for quicker light switch.
Technical Specifications
| Wavelength range: | 190~1100nm |
| Spectral bandwidth: | (0.5nm,1nm,2nm,4nm,5nm) Adjustable |
| Wavelength accuracy: | 0.3 nm |
| Wavelength repeatability: | <= 0.1 nm |
| Photometric accuracy: | 0.3%T |
| Photometric rang: | -0.3A-3A |
| Stray light: | <= 0.05%T |
| Stability: | +/- 0.001A/h @500nm |
| Baseline flatness: | +/- 0.001A |
| Wavelength and the setting mode: | Arbitrarily set |
| Scanning speed: | Fast, Mid, Slow |
| Wavelength setting method: | automatically |
| Detector: | Imported silicon photo diode |
| Light source: | Imported long-life tungsten lamp and Deuterium Lamp, |
| Display: | 12.59 x 9.45 in(320 x 240 mm) LCD |
| Data output: | USB Export |
| Printer : | Optional |
| Analysis Software: | Standard accessories |
| Input power: | AC220/50Hz or AC 110/60Hz |
| Weight: | 55.11 lbs.(25kg ) |
