Key Features
- It adopts 128*64-bit dot matrix LCD display which can directly display standard curve and tes data and the host can store test data
- Pint is optional for the instrument
Technical Specifications
| Optical system: | Czerny-turner CT grating monochromatic |
| Wavelength range: | 320-1100 nm |
| Wavelength accuracy: | +/- 0.5 nm |
| Wavelength repeatability: | 0.2nm |
| Measurement range: | 0-200%T,-03A-3A |
| Photometric accuracy: | 0.3%T |
| Photometric repeatability: | 0.2%T |
| Spectral bandwidth: | 2 nm |
| Zeroing: | Automatic |
| Stray light: | <= 0.05%T @360 nm |
| Stability: | +/- 0.002 A/h @500 nm) |
| Display modes: | 128*64 LCD |
| Basic Measurement: | T,A,C |
| Data output (print): | RS232C/USB |
| Light source: | Tungsten Lamp (6V10W) |
| Input voltage: | 220V/110VAC,50-60Hz |
