Features
- Quick and Precise Analysis: 32bit embedded processor secures high performance of the system,
- UK made Electrochemical/Tuel cell sensor. Highly specificity to alcohol, unaffected by other possible breath contaminants;
- Safe and Fasy to Use: All measurements functions are controlled via a single key, while menu navigation is by two menu keys
- Built in rechargeable lithium battery: Ensuring more than 8 hours testing:
- Printer: built in thermal printer
Technical Specifications
| Parameters | Details |
| Principle of measurement | Electrochemical sensor, alcohol-specific |
| Measurement range (BrAC) | 0.000mg/L ~ 2.500 mg/L |
| Resolution | 0.001mg/L |
| Accuracy | (-0.040-0) mg/L or Relative error -10%-0 |
| Repeatability | ≤ 2.5% |
| Calibration | Every 6 months |
| Temperature range-operation | -5°C to 45°C |
| Temperature range-storage | -30°C to 70°C |
| Optimum Storage Conditions | Temperature. 23°C ± 15°C; Humidity 50% ± 30% |
| Atmospheric pressure: ambient atmosphere pressure | |
| Other conditions: No vapor or electro-magnetic disturbances in the environment are influencing the normal working conditions of the device | |
| Hydrocarbon concentration in the environment: no more than 0.0021% | |
| Display | 2.8-inch 320 x 240 dot matrix color touch screen |
| Memory Capacity | Stores more than 4000 measured values with date and time |
| PC Interface | USB |
| Printer | Support external micro-Bluetooth Thermal or Dot Matrix Printer Optional |
| Dimension | 190.5mm x 82mm x 35mm |
| Weight | Approx. 450g |
| Operation Voltage | State of charging | State of operation |
| DC 10-14V | DC 6.3-8.4V | |
| Battery | 2000mAh / 7.4 Lithium-ion battery |
