Technical Specifications
| Power Source | 2 x 1.5 V AA UM3 Batteries |
| Current Consumption | 10 mA |
| DC Current Range Resolution Accuracy Overload Protection | (0 A to 4 A), 1 mA, ± 2.0 % ± 3 dgts, DC 40 A, 30 A, 10 mA, ± 2.0 % ± 3 dgts, DC 100 A, 40 A, 10 mA, ± 2.5 % ± 3 dgts DC 100 A |
| AC Current (True RMS, Crest Factor < 3) Range Resolution Accuracy | 50 Hz or 60 Hz, 40 Hz to 100 Hz |
| Overload Protection | 400 mA, 0.1 mA, ± 1.5 % ± 5 dgts, ± 2.0 % ± 5 dgts, AC 40 A, 50 Hz or 60 Hz 40 KHz to 1 KHz, 4000 mA, 1 mA, ± 2.5 % ± 5 dgts, ± 3.0 % ± 5 dgts, AC 40 A, 30 A, 10 mA, ± 2.0 % ± 5 dgts, ± 2.5 % ± 5 dgts, AC 100 A |
| DC Voltage (Input Impedance 10 M Ohm) Range Resolution Accuracy Overload Protection | 400 V, 0.1 V, ± 1.0 % ± 2 dgts, DC 1000 V |
| AC Voltage (Input Impedance 10 M Ohm, True RMS, Crest Factor < 3) Range Resolution Accuracy |
50Hz or 60 Hz, 40 KHz to 1 KHz |
| Overload Protection | 400 V, 0.1 V, ± 1.5 % ± 4 dgts, ± 2.0 % ± 5 dgts, AC 800 V |
| Power Consumption | 15 mA (approximately) |
| Low Battery Indication | Sampling Time 3 times or sec (display) 30 times or sec (bar graph) |
| Altitude | Up to 1.2 mi (2000 m) |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Operating Humidity | Less than 85% relative |
| Storage Temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Storage Humidity | Less than 75% relative |
| Dimensions | 7.2 in x 2.5 in x 1.4 in (183 mm x 61.3 mm x 35.6 mm) |
| Weight | 6.7 oz (190 g) (battery included) |
