Overview
This precision thermal wind speed meter is designed for accurate and reliable airflow measurement in a variety of environments. Built with a durable ABS body, it offers a high-resolution reading of 0.1, ensuring precise monitoring for both indoor and outdoor applications. The device operates using the metric system, making it suitable for standardized measurements across professional and industrial use cases. With its low starting wind speed capability of just 0.1, it can detect even the slightest air movements, making it ideal for HVAC testing, ventilation efficiency checks, and environmental monitoring. The compact design and straightforward operation make it user-friendly, while its robust construction ensures longevity in challenging conditions. This wind speed meter is an essential tool for technicians, engineers, and researchers who require dependable and accurate airflow data.
Features
- Thermal wind speed measurement technology
- 1 resolution for precise readings
- ABS construction for durability
- Low starting wind speed detection (0.1)
- Metric unit selection for standard measurements
- Compact and lightweight design
- Suitable for HVAC, ventilation, and environmental testing
Technical Specifications
| Device Type | Multifunctional Thermal Anemometer (Wind Speed, Air Volume, Temperature) |
| Display Type | Digital LCD with Backlight and Bar Graph |
| Measurement Parameters | Wind Speed, Air Temperature, Air Volume (CFM/CMM), Min/Max/Average, Current Reading |
| Wind Speed Range | 0 to 30.0 m/s (0 to 5860 ft/min, 55.0 knots, 90.0 km/h, 65.0 mph) |
| Wind Speed Resolution | 0.01 m/s |
| Wind Speed Accuracy | ±(0.03 m/s + 5% of reading) |
| Wind Speed Units | m/s, ft/min, knots, km/h, mph |
| Wind Volume Range | 0 – 999,900 m³/min (CMM) / 0 – 999,900 ft³/min (CFM) |
| Wind Volume Resolution | 0.001 – 100 (based on set area) |
| Air Volume Area Setting | 0.001 – 9999 (m² / ft²) |
| Air Flow Accuracy | ±3% of reading + 0.4 |
| Temperature Sensor Type | NTC |
| Temperature Range (Sensor) | -20°C to +70°C (-4°F to 158°F) |
| Temperature Accuracy | ±0.5°C (0°C to 60°C), ±0.7°C (outside range) |
| Temperature Resolution | 0.1°C / 0.1°F |
| °C/°F Selection | Yes |
| Sampling Methods | Diffusion and Built-in Pump |
| Current/Avg/Max/Min Measuring | Yes |
| Data Hold Function | Yes |
| Data Storage Capacity | 500 Groups |
| USB Data Connection | Yes (optional – for data download and analysis) |
| Alarm Modes | Vibration Alarm + 90 dB Audible + Visual Alarm (LEDs) |
| Battery Type | 9V Block Battery (6F22) or 3.7V Rechargeable Lithium Battery (model-dependent variation) |
| Battery Life | Approx. 20 Hours (9V) or ≥10 Hours (Rechargeable Lithium Battery) |
| Power Supply | Battery Powered with USB/AC Charging (110–240V AC, 50/60Hz) |
| Self-Test Functions | Sensor, Circuit, Display, Alarm Integrity |
| Explosion-Proof Rating | Exib IIC T3 |
| Ingress Protection (IP Rating) | IP66 |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Operating Temperature | -20°C to +50°C (-4°F to 122°F) |
| Operating Humidity | 0 to 95% RH (Non-condensing) |
| Material / Shell | ABS or ABS + PC (additional rugged rubber outer design in some models) |
| Dimensions | 182 × 64 × 40 mm / 133 × 70 × 36 mm / 205 × 75 × 32 mm |
| Dimensions (inches) | Approx. 5.24 – 8.07 in × 2.52 – 2.95 in × 1.26 – 1.57 in |
| Weight | 285 g – 360 g (0.63 – 0.79 lb) |
