Features
- Three-in-one tool: Measures acceleration, velocity, and displacement—no extra gadgets needed.
- Dual-range acceleration: Adjust between low-frequency and high-frequency bands for tailored diagnostics.
- Data output ready: AC signal output allows recording and post-analysis—great for predictive maintenance.
- Auto power-off: Convenient, but no manual power switch—don’t forget the 9 V battery.
- Acceptable accuracy: ±5% isn’t lab-grade, but it’s fine for on-site condition checks.
- Compact and lightweight: Pocketable at ~130 g—easy to carry around during inspections.
- OEM-ready: Customization possible, but assume extra cost.
- Warranty included: 1-year coverage is standard—expect basic support.
- Missing rugged specs: No IP rating—keep it away from water or severe dust.
Technical Specifications
| Specification | Details |
| Measurement Modes | Acceleration, Velocity, Displacement |
| Acceleration Range | 0.1 to 199.9 m/s² (Peak, RMS × 1.414) |
| Velocity Range | 0.1 to 199.9 mm/s (RMS) |
| Displacement Range | 0.001 to 1.999 mm Peak-to-Peak (RMS × 2.828) |
| Acceleration Frequency Options | Low: 10 Hz to 1 kHz; High: 1 kHz to 15 kHz |
| Display | Direct LCD display |
| Signal Output | AC signal output socket for analysis/recording |
| Power Supply | 1 × 9 V battery (6F22); auto power-off; no manual switch |
| Accuracy | ±5% + 2 digits |
| Size (Dimensions) | 140 × 70 × 30 mm (5.51 × 2.76 × 1.18 in) |
| Weight | 130 g (excluding battery) (~4.6 oz) |
