Features
- All-English LCD display with white backlight for easy use in the dark.
- Measures acceleration peak and displacement peak-to-peak data.
- User-configurable low-pass filter for stable results.
- Stores up to 100 data entries with time records.
- Warning limit preset with alarm for exceeded values.
- Long-lasting rechargeable Li battery with charge control circuit.
- Optimized filtering ensures stable and accurate results in noisy environments.
Technical Specifications
| Specification | Details |
| Testing Range | Acceleration: 0.1 m/s² to 199.9 m/s² (peak) Velocity: 0.01 cm/s to 19.99 cm/s (RMS) |
| Frequency Range | Acceleration: 10 Hz to 10 kHz Velocity: 10 Hz to 1 kHz Displacement: 10 Hz to 500 Hz |
| Tolerance | ±5% |
| Display | LCD, 128 x 64 pixels with LED backlight |
| Data Memory | 10 x 10 (100 readings total) |
| Continuous Working Time | About 100 hours |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Weight | 3.3 lb (1.5 kg) |
| Dimensions | 11.02 x 3.15 x 9.65 in (28 x 8 x 24.5 cm) |
