Features
- Bus-powered, requiring no external source.
- Detects all types of grounding faults.
- Works despite high distributed capacitance.
- Voice prompts for quick fault finding.
- Analyzes line leakage current to pinpoint faults.
- A spectrum analysis function improves detection accuracy.
- Safe, low-power output protects other devices.
- Universal current clamp; adjustable and automatic.
- Locates various ring network faults.
- Can solve mutual faults across different DC poles.
- Can test battery grounding and bus capacitance.
- Can test insulation without shutting down power.
Technical Specifications
Analyzer |
|
| Working voltage | take power directly from the bus (working voltage is 48V ~ 280V) |
| Voltage measurement range | 0 V to 300V |
| Voltage measurement accuracy | 0.5% |
| Bridge working mode | unbalanced bridge |
| The measurement range of positive to ground insulation impedance of the system | 0 kΩ to 999.9 kΩ |
| AC power channelling voltage measurement range | 0 V to 280 V |
| Power consumption | less than 10W |
| Suitable temperature | 14 °F to 122 °F (-10℃ to 50℃) |
| Overall dimension (L × w × h) | 7.87 in × 5.71 in × 1.81 in (20 cm x 14.5 x 4.6 cm) |
Locator |
|
| Working voltage | 12V (working voltage of lithium battery is 9.6V to12.6V) |
| Detection range of branch grounding resistance | 0 kΩ to 300 kΩ |
| Branch grounding resistance measurement accuracy | 0 to 100kΩ ≤10％±2kΩ 100 to 300kΩ display specific value |
| Leakage current detection sensitivity | less than 0.1mA |
| Measurement accuracy | 100% |
| Alarm mode | voice, graphics, data, grounding direction |
| Power consumption | less than 1W |
| Suitable temperature | 14 °F to 122 °F (-10℃ to 50℃) |
| Overall dimension (L × W × H) | 7.87 in x 5.71 in x 1.81 in (18 cm x 10 cm x 4 cm) |
| Weight | 3.31 lbs (1.5 kg) |
| Working power supply | lithium battery (12V 3100mAh rechargeable) |
