Features
- Pocket-sized and portable for easy field measurements
- Powered by internal rechargeable battery for mobility
- 8MB internal U-disk storage for waveform data and images
- Based on ARM Cortex-M3 core with FPGA for data control
- Supports multiple application firmware upgrades
- Ideal for electronics repair, experiments, and engineering tasks
Technical Specifications
| Oscilloscope Type | Digital |
| Sampling Rate (Max) | 100MSa/s |
| Resolution | 400 × 240 |
| Analog Input Impedance | 1MΩ |
| Coupling | DC Or AC |
| Vertical Sensitivity | 10mV/Div To 10V/Div (1-2-5 Sequence) |
| Horizontal Sensitivity | 100nS/Div To 1S/Div (1-2-5 Sequence) |
| Math Waveforms | INV A, INV B, A+B, A-B, C&D, C|D, RecA, RecB, RecC, RecD |
| Synchronous Modes | Auto, Normal, Single, Slow |
| Max Sample Memory Depth | 4K |
| Inbuilt Signal Generator | Sine, Square, Triangle, Sawtooth Wave |
| Battery Type | Internal 1000mAh Lithium battery |
| Operating Temperature | 32 °F To 104 °F (0 °C to 40 °C) |
| Product Weight | 0.22 lb (0.1 kg)Estimated Typical For Pocket Device |
| Dimensions | 3.92 in x 2.30 in x 0.53 in (9.95 cm x 5.85 cm x 1.35 cm) |
