Technical Specifications
| Chipset | AR9341 |
| Memory | 64 MB DDR or 16 MB Flash |
| Transmission Rate | 300 Mbps |
| Frequency Range | 2.4 GHz to 2.4835 GHz |
| Antenna | Built-in 13 dBi |
| Power Supply | 48 V PoE |
| Physical Ports | 1 LAN (10 to 100 Mbps) RJ45, 1 WAN (10 to 100 Mbps) RJ45, 1 Reset/WPS port |
| Output Power (Max) | 500 mW (27 dBm) |
| Receiving Sensitivity (Max) | -96 dBm |
| IP Index | IP65 |
| MTBF | Greater than 250,000 hours |
| Installation Options | Wall-mounted or pole-mounted |
| Dimensions | 11.81 inches x 7.09 inches x 1.97 inches (300 mm x 180 mm x 50 mm) |
| Weight | 4.41 lb (2 kg) |
| Temperature Range | 14 °F to 149 °F (-10 °C to 65 °C) |
| Humidity Range | 10% to 90% (non-condensing) |
