Features
- Breakthrough in safe, fast non-contact grounding resistance testing
- Time-saving loop measurement without disconnecting leads
- Clamp meter for unconventional grounding fault detection
- Alarm, storage, and data retention features
Technical Specifications
| Jaw Size | 2.5 in x 1.25 in (65 mm × 32 mm) |
| Resistance Range | Measuring range 0.010 Ω to 0.099 Ω 0.10 Ω to 0.99 Ω 1.0 Ω to 49.9 Ω 50.0 Ω to 99.5 Ω 100 Ω to 199 Ω 200 Ω to 395 Ω 400 Ω to 590Ω 600 Ω to 880 Ω 900 Ω to 1200 Ω |
| Power Supply | 6 V DC (4 No.5 alkaline dry cells LR6) |
| Single Measurement Time | 0.5 second |
| Liquid Crystal Display | 4 LCD digital display, length and width 47mm × 28.5mm |
| Data Storage | 99 group |
| Sound And Light Alarm | Beep— beep— beep Alarm sound, press AL key to turn on and off |
| Alarm Threshold Setting Range | Resistance: 1 Ω to 199 Ω |
| Jaw Opening Size | 1.25 in (32 mm) |
| Protection Level | Double insulation |
| Shift Fears | Fully automatic shift |
| External Magnetic Field And Electric Field | < 40 A/m; < 1 V/m |
| Resistance Measurement Frequency | > 1 KHz |
| RS232 Interface | Options |
| Attached Accessories | Clamp meter: 1 piece; test ring: 1 piece; battery LR6: 4 pieces; instrument box: 1 piece |
| Clamp Gauge Size | Length width thickness 11.3 in x 3.3 in x 2.2 in (285 mm × 85 mm × 56 mm) |
| Quality Of Clamp Watch | 2.5 lb (1.16 kg) (including battery) |
