Features
- No moving parts
- Virtually no pressure drops
- Minimal maintenance
- Wide range of nominal diameters
- Broad selection of lining and electrode materials
Technical Specification
| Power Supply | 110 V to 240 V AC (Optional: 24 V DC) |
| Power Consumption | 10 W |
| Accuracy | ±0.5% accuracy of rate from 0.3 m/s to 10 m/s
±1.0% accuracy of rate from 0.1 m/s to 0.3 m/s |
| Repeatability | 0.2% |
| Minimum Fluid Conductivity | 5.0 micromhos/in |
| Flow Direction | Unidirectional or bidirectional, 2 separate totalizers (programmable) |
| Analog Output | 4 mA to 20 mA, 750 ohms Max Load |
| Output Frequency | Scaled Pulse output, (open collector) Max 5 Khz |
| Noise Damping | Programmable |
| Pulse Width | Programmable up to 500 ms |
| Zero-Point Stability | Automatic correction |
| Ambient Temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Electrode Materials | SS316L; Optional: Titanium; Hastelloy Alloy C; Tantalum |
| Liner Material | PTFE, FEP, Hard Rubber |
| Fluid Temperature | PTFE: 248 °F (120 °C) Standard (Customized: 356 °F (180 °C)) Rubber: 140 °F (60 °C) |
| Pressure Limits | 145.04 PSI (1.0 Mpa), Optional 232.06 PSI, 362.6 PSI, 580.2 PSI (1.6 Mpa, 2.5 Mpa, 4.0 Mpa) |
| Coil Power | Pulsed DC |
| Pipe Spool Material | SS316 |
| Meter Housing Material | Carbon Steel welded or SS304 (Sanitary Connection) |
| Flange | Carbon Steel – Standard (ISO 7005-1), ANSI, DIN and JIS Flange Connections, Optional Stainless Steel Grounding Rings |
