Technical Specifications
| Max. LAN Data Rate | 1750 Mbps |
| With Modem Function | NO |
| Wi Fi Supported Frequency | 2.4G & 5G |
| 2.4G Wi Fi Transmission Rate | 600 Mbps |
| Type | Wireless |
| Standards And Protocols | Wi Fi 802.11g, Wi Fi 802.11b, Wi Fi 802.11n, Wi Fi 802.11ac, Wi Fi 802.11ax |
| Encryption Type | WPA2 PSK, WPA2, WPA3, WPA PSK, WPA, WEP |
| LAN Ports | 4 |
| Supports WDS | Yes |
| Supports WPS | No |
| Wi Fi Transmission Standard | WiFi 802.11 ax |
| Wired Transfer Rate | 10 or 100 or 1000Mbps |
| Private Mold | Yes |
| Function | FireWall, QoS, VPN |
| WAN Ports | 1 x 10 or 100 or 1000Mbps |
| 5G Wi Fi Transmission Rate | 1733 Mbps |
| CPU | IPQ6000 or 6010 or 6018 or 6028 |
| RAM | DDR3: 8Gbites |
| Flash | 2Gbits+SPI NOR 16MB |
| Support | 5G |
| Firmware | OpenWRT or Yinuolink or Customer’s |
| Interface | 1WAN or 4LAN or 1 x RS485 or 1 x 2.0USB or 1 x TF or 1 x 5G SIM or 1 x RESET or 1 x DC |
| Wireless Speed | 2.4G:573Mbps + 5.8G: 1201Mbps |
| Working Temperature | -40 °F to 167 °F (-40 ℃ to 75 ℃) |
| Dimensions | 8.11 Inches x 4.76 Inches x 1.22 Inches
(206 mm x 121 mm x 31 mm) |
