Features
- Supports multiple output modes: RS-485, LoRa wireless, 4-20 mA, 0-5V/0-10V analog.
- Measures vibration velocity & displacement (and optionally acceleration), plus temperature.
- Wide frequency range options (10-1600 Hz, or extended to 10-5000 Hz) for different vibration spectral needs.
- Durable in harsh industrial conditions: ‒40 °C to +80 °C operating temp; IP67 protection.
- Power options: DC 10-30V or a 3.6V lithium battery for LoRa version.
- High resolution & accuracy: velocity resolution ~0.1 mm/s; accuracy ±1.5% FS at certain conditions.
Technical Specifications
| Specification | Details |
| Output Types | RS-485, LoRa, 4-20 mA, 0-5V, 0-10V analog |
| Supply Voltage | 10-30 V DC (standard); 3.6 V lithium battery (wireless/LoRa version) |
| Frequency Range | 10-1600 Hz (standard); optionally 10-5000 Hz for extended spectral response |
| Vibration Speed Range | 0-50 mm/s RMS |
| Vibration Velocity Resolution | 0.1 mm/s |
| Accuracy | ±1.5% FS at 1 kHz, 10 mm/s reference |
| Detection Direction / Axes | Single-axis or three-axis variants available |
| Operating Temperature | ‒40 °C to +80 °C → ‒40 °F to +176 °F |
| Protection Class | IP67 |
| Material / Enclosure | Stainless steel shell; durable housing |
| Mounting Options | Threaded (M8, M5), magnetic mount (optional) |
| Temperature Measurement | Surface temp measured; resolution ≈ 0.1 °C |
