Overview
Experience seamless connectivity with a multi-functional device offering default Wi-Fi, Bluetooth, 4G LTE, phone capabilities, GPS, and an 8MP camera
Technical Specifications
| ID card Identification (Optional) | |
| Security Module Distance Frequency NFC Reader (Optional) Frequency Protocol Range |
ID verification system dedicated module 0 cm to 5 cm 13.5MHz±7kHz 13.56MHz Support ISO14443A/B, 15693 agreement 2 cm to 5 cm |
| Structural Parameter | |
| Dimensions Weight Display Screen Expand Port Communication Interface Input Mode Battery Capacity Frequency Key |
Dimensions 159 mm×75 mm×18 mm <500g 5.7-inch IPS color display with resolution 720*1440 SIM card, micro SD (TF) Card Type-C USB Standard Stylus, Handwriting, touching input or keyboard input, Function key×4 Rechargeable polymer battery (3.8V 4200mAh) removable 8ohm 1W speaker Silicone button |
| Performance Parameter | |
| OS CPU RAM Flash ROM Data Communication WI-FI FDD/TDD-LTE 4G WCDMA 3G GSM 2G Bluetooth |
Android 9.0 Cortex-A53 Octa-core 64-bit 2.0GHz high-performance processor 3G or4G RAM Standard 32G/64G NAND Flash Storage micro SD/TF port (Max up to 128G) Dual-band 2.4GHz / 5GHz, Supporting IEEE 802 a/b/g/n/ac protocol FDD: B1 or B3 or B4 or B7 or B8 or B12 or B20 TDD: B38 or B39 or B40 orB41 WCDMA (850 or 900 or 1900 or 2100MHz) GSM (850 or 900 or1800 or1900MHz Support Bluetooth 2.1+EDR or 3.0+HS/ 4.1+HS Transmission distance 5-10 meters |
| Standard Modules | |
| Rear Camera Front Camera GNSS |
13MP HD camera, Support auto focus, Flash, Anti-shake, Macro shooting 2MP color camera Support GPS, Galileo, Glonass, Beidou |
| Operating Environment | |
| Operating Storage Temperature Environment Humidity Drop Specifications Roll Specifications Sealed Environment |
-20°C to 55°C -40°C to 70°C 5 % RH95 % RH (no condensation) 6 sides Supports 1.5 meters drops and 30 times to the concrete within the operating temperature 500×0.5m rolling for 6 sides IP66 |
| 2D CMOS (OPTIONAL) | |
| CMOS Scanner The Sensor Resolution Ambient Light Focus Element (VLD) Support bar code type |
Honeywell N3601 Honeywell N6603 752(level)×480(vertical)Pels(gray level) All dark 9000ft.candles/96900 lux 655nm ± 10nm PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, micro QR code,Aztec, MaxiCode; Postal Codes: US PostNet,US Planet, UK Postal, Australian Postal, JapanPostal Dutch Postal (KIX)3 |
| Fingerprint Recognition (Optional) | |
| Sensor Sensor Type Function Resolution Memory |
TCS2SS Capacitive Sensor Enrollment, Compare, Deletion etc. 508DPI 1,000 PCS Fingerprints |
