Technical Specifications
| Max Output Efficiency | 720 W |
| Output Power Mode | 120 or 230 V auto recognition |
| Open Circuit Voltage Rand of Solar Panel | 33 to 54 VOC |
| Peak Power Tracking Voltage | 22 to 60 V |
| Minimum or Maximum Starting Voltage | 22 to 60 V |
| Maximum Short Circuit Current | 32 A |
| Maximum Output Working Current | 27 A |
| Output Peak Power | 760 W at 120 V and 230 V |
| Rated Output Power | 700 W at 120 V and 230 V |
| Rated Output Current | 6 A at 120 V and 3 A at 230 V |
| Rated Voltage Range | 85 to 160 V at 120 V and 185 to 256 V at 230V |
| Rated Frequency Range | 47 to 52 or 57 to 62 Hz at 120 V and 230 V |
| Power Factor | Over 94 % |
| Number Of Circuit Connections Per String | 6 pcs (single) 120 V and 12 pcs (single) 230 V |
| Static MPPT Efficiency | 99.5 % |
| Maximum Output Efficiency | 95 % |
| Power Loss At Night | Less than 0.5 W |
| Total Harmonic Distortion | Less than 5 % |
| Working Temperature Range | – 4 °F to 122 °F (- 20 °C to 50 °C) |
| Waterproof Range | IP 65 |
| Heat Dissipation Mode | Self cooling |
| Communication | 433 MHz and WIFI and lot |
| Size | 11.14 in x 7.87 cm x 1.64 cm (28.3 cm x 20 cm x 4.16 cm) |
| Weight | 3.17 lb (1.44 kg) |
