Technical Specifications
| Recommend Use Panels | 4 of 875 Watt |
| Output Voltage Mode | 120 or 230 V Auto switch |
| PV Open Circuit Voltage | 33 to 60 VDC |
| Operating Voltage Range | 22 to 60 V |
| Starting Voltage Range | 22 to 60 V |
| Short-Circuit Current | 4 of 32 A |
| Maximum Working Current | 4 of 27 A |
| Output Peak Power | 3000 Watt at 120 V
3000 Watt at 230 V |
| Rated Output Power | 2800 Watt at 120 V
2800 Watt at 230 V |
| Output Current | 23.5 A at 120 V
12.2 A at 230 V |
| AC Voltage Range | 85 to 160 VAC at 120 V
180 to 265 VAC at 230 V |
| AC Frequency Range | 48 to 51 Hz or 58 to 61 Hz at 120 V
48 to 51 Hz or 58 to 61 Hz at 230 V |
| Power Factor | Over 95% at 120 V
Less than 95 % at 230 V |
| Number of Branch Connections. | 2 PCS (Single) at 120 V
4 PCS (Single) at 230 V |
| Static MPPT Efficiency | 99.5 % at 120 V
99.5 % at 230 V |
| Max Output Efficiency | 95 % at 120 V
95 % at 230 V |
| Loss Of Power At Night | Less than 0.5 W at 120 V
Less than 0.5 W at 230 V |
| Total Current Harmonics | Less than 5 % at 120 V
Less than 5 % at 230 V |
| Temperature Range | – 4 °F to 122 °F (- 20 °C to 50 °C) |
| Waterproof Grade | Ip 65 NEMA3R |
| Heat Dissipation Mode | Self-cooling |
| Communication Mode | WIFI |
| Power Transmission Mode | Reverse transmission and Load priority |
| Monitoring System | APP |
| Electromagnetic Detection | EN 61000 – 6 – 1 : 2007 EN 6100 – 6 – 3 : 2007 and A 1 : 2011 and AC : 2012 |
| Power Grid Standard | EN 50549 – 1 and EN 50549 – 2
NBR 16149 : 2013 UL 1741 |
| Power Grid Detection | IEC or EN 62109 – 1 and IEC or EN 62109 – 2 and IEC 62116 and IEEE 1547 |
| Size | 14.57 in x 11.81 in x 1.64 in (37 cm x 30 cm x 4.16cm) |
| Weight | 6.97 lb (3.16 kg) |
