Technical Specifications
| Chipset | SX1302 |
| Application | LoRaWAN |
| Type | LoRa Module |
| Supplier Type | Manufacturer |
| Color | White |
| Working Frequency | 433/470/868/915 Multi-band Optional |
| Communication Rate | 250bps to 5.4 KBPS (@125 kHz) |
| Transmitting Power | +27dBm Max (antenna port +26dBm Max) |
| Reception Sensitivity | SF10 ≤ 136dBm |
| Antenna Gain | -5dBi Glue Stick Antenna (optional) |
| Business Channel | 8 Channel Uplink, 1 Channel Downlink |
| Working Mode | Half Duplex, Same Frequency/Different Frequency |
| USB | 4-way Interface |
| Data | Return Ethernet |
| Debugging Interface | Wi-Fi Hot Spot Nearby Management |
| Power Supply Parameter | 9V to 36V DC |
| Power Supply Mode | Supports DC Power Supply and POE Power Supply |
| Complete Machine Power Consumption | 3.6 W (Typical Value) |
| Relative Humidity | 5% to 95%, No Frost |
| Working Temperature | -13°F to 158°F (-25℃ to 70℃) |
| Storage Temperature | -40°F to 185°F (-40℃ to 85℃) |
