Features
- Gas type can be customized
- Integrated built-in LoRaWAN collector
- Solar panels can be integrated
- Variety of wireless modules
- Durable and water-resistant design
Technical Specifications
| Stability | < 1% during the life of the sensor |
| Response Time | < 1 second |
| Working Current | 85 mA at 5 V, 50 mA at 12 V, 40 mA at 24 V |
| Output | RS485, MODBUS communication protocol |
| Housing Material | ABS |
| Standard Cable Length | 6.56 ft (2 m) |
| The Farthest Lead Length | RS485 3280.84 ft (1000 m) |
| Protection Level | IP65 |
| Communication | LoRaWAN, RS485 |
| Power Supply | Battery, DC 12 V, Solar Panel |
| Waterproof Rating | IP65 |
| Wireless Transmission | LoRa or LoRaWAN (868 MHz, 915 MHz, 434 MHz) |
| Customizable | GPRS, 4G, Wi-Fi |
| Stand Pole | 4.92 ft (1.5 m), 6.56 ft (2 m), 9.84 ft (3 m) height |
| Equipment Case | Stainless steel waterproof |
| Ground Cage | Can supply the matched ground cage to burried in the ground |
| Cross Arm For The Install | Optional (Used in thunderstorm places) |
| Solar Panels | Power can be customized |
| Solar Controller | Can provide matched controller |
| Mounting Brackets | Can provide the matched bracket |
| Humidity Range | 0 % to 100 % RH |
| CO Detection Range | 0 to 1000 ppm |
| O₂ Detection Range | 0 to 25% |
| O₃ Detection Range | 0 to 10 ppm |
| Installation Height | 3.3 ft to 9.8 ft (1 m to 3 m) |
| Device Dimensions | 7.09 in x 5.51 in x 1.97 in (180 mm × 140 mm × 50 mm) |
| Working Environment | Temperature -22 °F to 158 °F (-30 °C to 70 °C), working humidity: 0 % RH to 100 % RH |
| Storage Conditions | -40 °F to 140 °F (-40 °C to 60 °C) |
| Weight | 17.6 oz (500 g) |
| Transmission Range | 6.2 mi (10 km) |
