Applications
- Motor
- Fan
- Water pump
- Bearing
- Air compressor
- CoaI mining Machinery
- Gas engine
Technical Specifications
| Parameters | Details |
| Sensitivity | 50 mV/mm/s ±5% |
| Frequency Response | 5 to 1000 Hz |
| Natural Frequency | 10 Hz |
| Measurement Range (Vibration Severity) | 0 to 10 mm/s, 0 to 20 mm/s, 0 to 30 mm/s, 0 to 50 mm/s, 0 to 100 mm/s, 0 to 150 mm/s |
| Measurement Range (Vibration Displacement) | 0 to 100 µm, 0 to 200 µm, 0 to 500 µm, 0 to 1000 µm, 0 to 2000 µm |
| Measurement
|
Vibration velocity/displacement
Stainless steel housing material IP67 dust proof and waterproof design |
| Output signal (options) | 4-20mA /0-5V 10-1 OV / RS485 |
| Power supply | 24VDC |
| Output Signal | 4–20 mA, 0–5 VDC, 0–10 VDC, RS485 |
| Output Impedance | ≤ 500 Ω |
| Working Voltage | 24 VDC (18 VDC ~ 24 VDC) |
| Maximum Acceleration | 10 g |
| Measurement Direction | Vertical or Horizontal |
| Ambient Temperature | −40 °C to 60 °C |
| Relative Humidity | ≤ 90% |
| Appearance Dimensions | Ø34 × 72 mm |
| Mounting Method | Threaded installation M10 × 1.5 or magnetic seat installation |
| Relative humidity | ≤ 90 % |
| Accuracy | 3% |
| Weight | 350 g |
