Features
- Accurate on-site RMS measurements: Captures true RMS velocity from 0.01 to 199.9 mm/s—sufficient for machinery diagnostics, not micrometre-level lab work.
- Lightweight and mobile: At just 181 g plus 4 AA batteries, it’s easy to handle during inspections.
- Versatile output: USB and RS-232 for data export; optional Bluetooth means flexible connectivity, including electronic stethoscope functionality.
- Standard range specs: 10 Hz to 1 kHz covers most industrial vibration scenarios.
- Basic environmental resilience: Operates within 0–50 °C and up to 90% humidity.
- Simple but effective power system: Operates on standard AA batteries—battery lifespan may vary, so keep extras handy.
- Custom-ready: OEM, ODM, and OBM support available—expect lead times and price increases if you want branding or modifications.
- One-year warranty blocks some risk: Coverage is typical—but lack of rugged casing info means avoid harsh conditions.
Technical Specifications
| Specification | Details |
| Measurement Parameter | Velocity (True RMS) |
| Velocity Range | 0.01 to 199.9 mm/s True RMS |
| Frequency Range (Velocity) | 10 Hz to 1 kHz |
| Accuracy | ±5% of reading + 2 digits |
| Sensor Type | Piezoelectric transducer / accelerometer |
| Power Supply | 4 × AA (1.5 V) batteries |
| Operating Conditions | Temperature: 0 °C to 50 °C; Humidity: < 90% RH |
| Dimensions | 160 × 68 × 32 mm (6.30 × 2.68 × 1.26 in) |
| Weight (Without Batteries) | 181 g (0.40 lb) |
| Standards Compliance | ISO 2954 (periodic measurements for rotating machinery) |
| Data Output Options | USB, RS-232; optional Bluetooth adapter and headset for stethoscope function |
| Optional Accessories | Headset, RS-232 cable with software, Bluetooth adapter |
