Features
- Precision measurement: Achieves ±0.001 g/cm³ accuracy with fine resolution—solid enough for critical density monitoring, not lab-grade but damn close.
- Wide operating conditions: Functional in aggressive environments—accepts –50 °C to +200 °C and up to 20 MPa (in high-end variants) with no problem.
- Robust outputs: Analog 4–20 mA plus digital RS-485 Modbus RTU gives you flexibility for legacy or smart systems.
- Built tough and easy to install: IP65-rated, made of industrial-grade materials (SS, Hastelloy, Ti), with insertion depths up to 2 meters—no moving parts to fail.
- Smart compensation built-in: PT100 sensor handles temperature drift, so your accuracy doesn’t tank with a few °C swings.
- OEM-ready: Process connection types flexible—threaded or flanged—suits various tank or pipeline setups.
- Heavy but stable: About 10 kg means you’ll need solid mounting—portable by forklift, not hand-carried.
- Cert-compliant: CE and RoHS—no shady wiring or dodgy approvals.
- Real endurance: Designed for noon-breaking industrial flow, not the fragile stuff many units claim to handle.
Technical Specifications
| Specification | Details |
| Measurement Type | Inline tuning-fork densitometer for liquids |
| Density (Measurement) Range | 0–3 g/cm³ (0–3000 kg/m³) |
| Accuracy | ±0.001 g/cm³ (±1 kg/m³) |
| Resolution | 0.0001 g/cm³ |
| Temperature Range | –50 °C to +200 °C |
| Fluid Viscosity Range | Up to 20,000 cP |
| Temperature Coefficient | 0.1 kg/m³ per °C |
| Built-in Temperature Sensor | PT100 |
| Power Supply | 20–28 V DC @ 35–45 mA |
| Analog Signal Output | 4–20 mA, isolated, non-self-powered |
| Digital Interface | RS-485 Modbus RTU available |
| Process Connection | 1.5″ NPT thread; DIN 50 PN40 / PN100 flange; other standards optional |
| Protection Level | IP65 |
| Wetted Materials | Stainless Steel, Hastelloy C22, Titanium Alloy, etc. |
| Fork Body Coating | Standard, PTFE, or electrolytic polishing |
| Insertion Depth | 125 mm to 2000 mm |
| Weight | Approx. 10 kg per set |
| Certifications | CE, RoHS |
| Special Features | Plug-in type, no moving parts, maintenance-free, temperature compensation |
