Overview
Hospitality Enviro Tech’s Industrial Touchscreen Data Collector with Wi-Fi and ERP Integration data collection workstation is a data collector designed to help enterprises improve production efficiency. It integrates workstation information display, data collection and transmission, and human-machine interaction into a unified design, with customizable title content. The collection system can also communicate with the user’s current information management terminals such as ERP and other management tools to achieve data docking. It is reusable and energy-saving.
Features
- 7-inch high-definition capacitive touch screen
- Customizable title based on business needs
- Customizable display content
- Supports TTS voice broadcast
- WIFI or Ethernet available
- Supports IC or ID card reading
- Supports RS232 expansion for external hardware, sensors, and other smart devices
- Supports external USB/serial port scanning devices
- Supports USB drive upgrade
- Supports USB drive upgrade
- Supports docking with user’s enterprise MES/ERP and other systems
Technical Specifications
| Parameters | Details |
| Voltage | DC12V/2A |
| Display | 7 inches |
| Pixels resolution | 1024*600 |
| Touch | Capacitive |
| Size | 186.3×138.5x31mm |
| Network | WIFI Ethernet/Wi-Fi |
| Brightness | 250cd/㎡ |
| USB | 1×USB2.0 |
| Serial Port | 1×RS232 |
| IO Output | 3 outputs |
| IO Input | 3 inputs |
| Audio | 8Ω 2W speaker |
| Card Reading | IC/ID card |
| Operating Temperature | -20℃ to -60℃ |
