Features
- Pure sine wave solar inverter
- WIFI for IOS and Android
- Built-in 40 A MPPT controller
- Wide PV input voltage range
- Built-in anti-dust kit
- Compatible lithium battery
Technical Specifications
| Rated Power | 3200 VA or 3000 W |
| Voltage | 230 VAC |
| Selectable Voltage Range | 170 to 280 VAC (For Personal Computers)
90 to 280 VAC (For Home Appliances) |
| Frequency Range | 50 Hz or 60 Hz (Auto sensing) |
| AC Voltage Regulation | 230 VAC plus or minus 5 % |
| Surge Power | 6400 VA |
| Efficiency (Peak) PV to INV | 98 % |
| Efficiency (Peak) Battery to INV | 94 % |
| Transfer Time | 10 ms (For Personal Computers)
20 ms (For Home Appliances) |
| Battery Voltage | 24 VDC |
| Floating Charge Voltage | 27 VDC |
| Overcharge Protection | 33 VDC |
| Maximum AC Charge Current | 60 A |
| Maximum PV Array Power | 3000 W |
| MPPT Range at Operating Voltage | 30 to 400 VDC |
| Maximum PV Array Open Circuit Voltage | 400 VDC |
| Maximum Charging Current | 80 A |
| Communication Interface | RS 232 or GPRS or WIFI |
| Humidity | 5 % to 95 % Relative Humidity (Non condensing) |
| Operating Temperature | 14 °F to 104 °F (- 10 °C to 50 ℃) |
| Dimension | 14.06 in 10.75 in x 3.74 in (35.7 cm x 27.3 cm x 9.5 cm) |
| Net Weight | 10.14 lb (4.6 kg) |
