Features
- Pure sine wave inverter
- Built-in MPPT controller
- Selectable input voltage
- Selectable charging current
- Configurable AC and solar input
- Auto restart while AC is recovering
- Overload and short circuit protection
- Smart battery charger design
- Cold start function
Technical Specifications
| Rated Power | 4500 W |
| Voltage | 230 VAC |
| Selectable Voltage Range | 175 to 265 VAC (for personal computers) 90 to 265 VAC (for home appliances) |
| Frequency Range | 50 Hz or 60 Hz (auto sensing) |
| AC Voltage Regulation (Batt. Mode) | 230 VAC plus or minus 5 % |
| Surge Power | 2 rated power for 5 seconds |
| Efficiency (Peak) PV to INV | 97 % |
| Efficiency (Peak) BAT to INV | 94 % |
| Transfer Time | 10 ms (for personal computer) 20 ms (for home appliances) |
| Waveform | Pure sine wave |
| Battery Voltage | 24 VDC |
| Bulk Charging | Voltage Flooded Battery 29.2 VDC AGM or GEL Battery 28.6 VDC |
| Floating Charge Voltage | 27.6 VDC |
| Overcharge Protection | 32 VDC |
| Max Charge Current | 150 A |
| Max PV Array Power | 6000 W |
| MPPT Range at Operating Range | 120 to 450 VDC |
| Max PV Array Open Circuit Voltage | 4450 VDC |
| Max Charging Current | 150 A |
| Maximum Efficiency | 99 % |
| Communication Interface | RS 485 or RS 232 (Standard) and LCD Remote and WIFI (optional) |
| Humidity | 5 % to 95 % Relative Humidity (Non-condensing) |
| Operating Temperature | 32 F to 131 F (0 °C to 55 °C) |
| Storage Temperature | 5 F to 140 F (- 15 °C to 60 °C) |
| Dimension | 18.43 in c 12.52 in x 6.26 in (46.8 cm 31.8 x 15.9 cm) |
| Weight | 17.64 lb. (8000 g) |
