Features
- 2 in TFT LCD high brightness
- Support USB interface and large capacity
- Effective support long term information collection
- Powerful PC analysis software
- Data acquisition, monitoring, recording and controlling
Technical Specifications
| Power supply | AC 85 V to 265 V, DC 12 V to 25V |
| Channel | 1 Channels to 64 Channels |
| Input signal | Thermocouples K, E, R, B, N, T, J, S. PT100, DC |
| DC (A) 4 mA to 20 mA,0 mA to 20 mA | |
| DC (V) 0 V to 5 V, 0 V to 10 V, ±312 mV, ±78 mV | |
| Sampling frequency | 1 s to 19999 s Self setting |
| Recording capacity | 1 Minute record interval 4200 Hrs. |
| Alarm type | High and low limit alarm. |
| Communication | RS 232, RS 485, Ethernet, USB, Modbus TCP Communication protocol |
| Material | Fire ABS |
| Operating temperature and humidity | -4 °F to 122 °F (-20 ℃ to 50 ℃), Less than 95% non-condensing |
