Technical Specifications
| Flow rate range | 0 per second to ± 10 per second, forward and reverse measurement |
| Measurement accuracy | ± 1 % |
| Pipe diameter | DN 15 to DN 6000 |
| Fluid types | Water, sea water, sewage, acid and alkali, alcohol, beer, various oils, etc., a single uniform liquid that can conduct ultrasonic waves |
| Pipe material | Steel, stainless steel, cast iron, copper, PVC, aluminum, glass fiber reinforced plastic and other dense pipes, lining allowed |
| Communication interface | Isolated RS485 serial interface, support MODBUS protocol |
| Data storage | SD card regularly stores the measurement results of the set parameter meter (optional) |
| Power supply mode | DC 8 V to 36 V or AC 85 V to 264 V |
| Signal output | 1 channel 4 mA to 20 mA current output, impedance 0 K to 1 K, accuracy 0.1 % 1 channel OCT pulse output, pulse width 6 ms to 1000 ms 1 relay output (optional) |
| Signal input | 3 channels of 4 mA to 20 mA current input (optional) Connect three-wire PT100 platinum resistance to realize heat measurement |
| Fluid temperature | -22 °F to 320 °F (-30 °C to 160 °C) |
