Features
- Analysis for Single Phase and Balanced 3 phase system
- True RMS Value (Voltage and Current)
- Large dual LCD Display with Backlight
- USB interface
- Data Hold, Minimum or Maximum measurement
- True power or apparent power or power factor measurement
- Auto Ranging & Auto Power Off
- Overflow Indication Manual Data Memory and Read (99 sets)
- NCV Detection
- 16 in (55mm) Jaw opening
Technical Specifications
| AC Voltage Range | 15 V or 100 V or 300 V or 750 V |
| AC Voltage Basic Accuracy | ± (1.2 % + 5) |
| AC Current Range | 40 A or 100 A or 400 A or 1000 A |
| AC Current Accuracy | ± (2 % + 5) |
| True Power | 0.60 kW to 750 kW |
| True Power Accuracy | ± (3 % + 5) |
| Apparent Power | 0.60 kVAr to 750 kVAr |
| Apparent Power Accuracy | ± (3 % + 5) |
| Reactive Power | 0.60 kVAr to 750 kVAr |
| Reactive Power Accuracy | ± (4 % + 20) of 15 V or 1000 A else ± (4 % + 5) |
| Power Factor | 0.3 to 1 |
| Power Factor Accuracy | ± (2 % + 20) |
| Phase Angle | 0° to 90° |
| Phase Angle Accuracy | ± 1° |
| Frequency | 20 Hz to 200 Hz |
| Frequency Accuracy | ± (0.5 % + 5) |
| Energy | 1 kWh to 9999 kWh |
| Energy Accuracy | ± (3 % + 2) |
| Dimensions | 11.6 in x 3.9 in x 46 in (295 mm x 100 mm x 46 mm) |
| Weight | 18.9 oz (537 g) |
