Technical Specifications
| Measuring Range | Oxygen content: 0.00 mg/L to 20.00 mg/L Saturation: 0 % to 200 % |
| Accuracy | oxygen content: ± 0.1 mg/L saturation: ± 1 % |
| Response Time | 0 > 100 %, T90 < 25 s, 100 > 0 %, T 90 < 30 s |
| Temperature Compensation | Automatic, built in temperature unit |
| Related Compensation | Salinity compensation, pressure compensation |
| Calibration Method | Zero calibration and full-scale calibration |
| Working Pressure | 0 bar to 3 bar |
| Material | Body: PPS Head: 316 SS |
| Connection | M16 |
| Power Supply | 6 V dc to 12 V dc |
| Installation Dimensions | A British 1 NPT of the head and the tail for each install thread |
| Protection Grade | IP68 |
| Accuracy Temperature | 0.5 °F (0.5 °C) |
| Measuring Range Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Dimensions | 1.37 in x 9.84 in (35 mm x 250 mm) |
| Weight | 0.57 lb (0.26 kg) |
