Features
- Two display modes: digital value mode and spectrum mode
- Large memory function: 100 x 100 measured results (100 testing points, 100 data can be stored in each testing points), 100 spectrograms (each testing point can store one spectrogram)
- Spectrogram can display in real time
- Histogram can be made according to the preset alarm line
- Upper /lower limits pre-setting and sound alarm if test results out of limitation, which leads to spectrum analysis mode automatically
- Connected to PC with advanced software for more analysis needs
- Connect to the printer to print out the testing result
- 300 x 200 matrix LCD display with backlight
- It’s equipped with low-sensitivity probes, suitable for testing strong vibration
- It’s equipped with high sensitivity probes, suitable for testing weak vibration
- Conform to ISO 2954, GB/T13824, GB138233 Standards
Technical Specifications
| Acceleration | 3.3 ft/s2 to 1286.1 ft/s2 1 m/s2 to 392 m/s2 (peak) |
| Velocity | 0.1cm/s to 80cm/s)(RMS) |
| Displacement | 0.000039 in to 0.078 in. (0.01 mm – 18.1 mm) (peak-peak) |
| Accuracy | ±5% |
| Frequency range | Acceleration: 10Hz to 200Hz, 10Hz to 500Hz, 10Hz to 1KHz, 10Hz to 10KHz Velocity: 10Hz to 200Hz, 10Hz to 500Hz, 10Hz to 1KHz Displacement: 10Hz to 200Hz, 10Hz to 500Hz |
| Power | Li battery (continuous working 20 hour without backlight |
| Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Humidity | <80% RH |
| Dimension | 6.73 in x 3.09 in x 1.1 in (171 mm x 78.5 mm x 28 mm) |
| Weight (g) | 0.551 lbs. (230g) |
