Key Features
- Operates at 159.2 Hz
- 10 mm/s RMS velocity output
- Drives vibration sensors up to 33 lbs (150 g)
- CE compliant
Technical Specifications
| Operating Frequency | 159.2 Hz ±0.5% |
| Acceleration Output | 10 m/s² (RMS) ±3% |
| Velocity Output | 10 mm/s (RMS) ±3% |
| Displacement Output | 10 um (RMS) ±3% |
| Transverse Output | <5% |
| Distortion | <3% |
| Maximum Load | 0.33 lbs (150 g) |
| Ramp-Up Time | < 3 Seconds |
| Operating Temperature | 14 °F ~ 104 °F (-10 °C ~ 40 °C) |
| Operating Humidity | <85% RH |
| Internal Battery | 1 x 9 V 6 F22 |
| Size | 2.20 in x 7.87 in (56 mm x 200 mm) (Diameter x Height) |
| Weight | 1.98 lbs (900 g) (with batteries) |
Additional Information
Applications:
- Vibration monitoring systems
- Recording systems
Accessories
- Main Unit
- Carrying Case
- Instruction Manual
To Change the Battery
When the battery needs to be replaced, please unscrew the base of the instrument and replace the battery inside. The instrument applies a 9 V battery. (As shown in Figure 1)
Note: the upper part of the instrument is a closed structured, do not try to unscrew it. If forcibly unscrew it, the internal circuitry may get damaged.
